HeatX – SQ51
HeatX-SQ51 is designed to meet industrial and automotive applications with harsh working conditions. Made from PPS, this robust tag offers great resistance to high-temperature, mechanical stress and most chemicals. The high-temperature tags have been successfully tested to sustain 220°C for 100 hours. Meanwhile, HeatX-SQ51 features a user-friendly screw mount package, making installation quick and hassle-free.
Specifications
| Dimensions (mm) | L 51 x W 51 xT 6.4 |
| Material | PPS |
| Frequency | HF/LF |
| Operating Temperature(°C) | -40 to 85 |
| Storage Temperature(°C) | -40 to 85 |
| Peak Temperature(°C) | 220/ 100hrs |
| IP Rating | IP68 |
| Applicable Surface | On-metal / Free-air |
| RFID Chip | NXP I CODE SLIX2 / FujitsuMB89R118 / EM4450 |
| RF Interface Protocol | ISO/IEC 15693 |
| Color | Black |
| Options | Screw Mount Laser Engraving Adhesive |
